Operation Manual / TPL67-C.. - TPL71-C..
8 Disassembly and assembly / 8.1 Introduction
© Copyright 2020 . All rights reserved. HZTL2488_EN Rev.G March 2020
WARNING
Suspended loads
Loads not suspended in compliance with regulations may lead to per-
sonal injury or accidents with fatal consequences.
u Attach turbochargers, assemblies or individual components only to
lifting gear which is in technically perfect condition and has a suffi-
cient load limit.
u Make sure the load is suspended properly on the crane hook.
u Do not let anyone stand beneath a suspended load.
Wear safety gloves to protect against mechanical hazards.
Wear safety helmet.
Definition of terms
¡ Suspension point
Defined load attachment point on a component or an assembly (blind
hole thread, eye, lug).
¡ Assembly device
Devices that are fitted on the turbocharger in order to obtain a sus-
pension point. Assembly devices are specially constructed and de-
signed for the defined use; they are not commercially available
products. Use assembly devices only for the described applications.
¡ Lifting gear
Equipment for lifting and transporting loads (lifting slings, chain
block, crane). Lifting gear is not supplied by ABB.
