The following table gives an example of the ASDU 10 Generic Data that is transferred
spontaneously for a diagnostic event.
Table 19: TYPE IDENTIFICATION: Generic data
0 0 0 0 1 0 1 0 Type Identification 10 DATA UNIT IDENTIFIER
1 0 0 0 0 0 0 1
Variable Structure
Qualifier
SQ=1,
SQ_No.= 1
Spontaneous <1>
Cause Of Transmission COT
REB500 CU/BU No.
Common Address of
ASDU
<0 .. 60>
GEN <254> Function type FUN
INFORMATION
OBJECT
Read value of single entry <244>
Information number INF
<0>
Return information
identifier
RII
{1, 0, 0}
Number of generic data
sets
NGD {NO, COUNT, CONT}
40 H
01 H
Generic identification
number
GIN
Example
Current value <1> Kind of description
KOD
DATA STRUCTURE
<23>
29
1,0
DATA TYPE
DATA SIZE
NUMBER, CONT
GDD
<1> OS8ASCII
12
1,0
DATA TYPE
DATA SIZE
NUMBER, CONT
GDD 1
Major Error
GID 1 (example)
<3>
UI
1
1,0
DATA TYPE
DATA SIZE
NUMBER, CONT
GDD 2
Error code (UI1)
GID 2
<14>
BINARY TIME
7
1,0
DATA TYPE
DATA SIZE
NUMBER, CONT
GDD 3
Time stamp (CP56Time2a)
GID 3
4.5.2 Status information
GUID-49587D6A-D1F8-43AD-ACBD-AEB285A3C396 v1
All the status information relating to binary input and output signals, internal signals (single-
point indications - SPI) and switchgear positions (double-point indications - DPI) that are
configured in REB500 for transfer via IEC60870-5-103, but are not covered by the compatible
part of the IEC recommendation, are transferred as generic data. An entry is made in the table
for every event configured using HMI500 or REBCON for transfer via IEC 60870-5-103. Since
there can be more events per type (SPI or DPI) than the maximum number of entries a group
can have (255), the system reserves additional groups as necessary. By this means, up to 1020
events per event type can be defined in the generic part.
1MRK 511 451-UEN B Section 4
IEC60870-5-103
Distributed busbar protection REB500 21
Communication protocol manual IEC60870-5-103
