Table 126. Functions included in the relay, continued
Description IEC 61850 IEC 60617 ANSI
Voltage vector shift protection VVSPPAM VS 78V
Three-phase underexcitation protection UEXPDIS X< 40
Three-phase underimpedance protection UZPDIS Z< GT 21GT
Circuit breaker failure protection CCBRBRF 3I>/I0>BF 51BF/51NBF
Tripping logic TRPPTRC I -> O 94
Multipurpose analog protection MAPGAPC MAP MAP
Control
Bay control QCCBAY CBAY CBAY
Interlocking interface SCILO 3 3
Circuit breaker/disconnector control GNRLCSWI I <-> O CB/DC I <-> O CB/DC
Circuit breaker DAXCBR I <-> O CB I <-> O CB
Disconnector DAXSWI I <-> O DC I <-> O DC
Local/remote switch interface LOCREM R/L R/L
Synchrocheck SYNCRSYN SYNC 25
Generic process I/O
Single point control (8 signals) SPC8GGIO - -
Double point indication DPGGIO - -
Single point indication SPGGIO - -
Generic measured value MVGGIO - -
Logic Rotating Switch for function selection and LHMI
presentation
SLGGIO - -
Selector mini switch VSGGIO - -
Pulse counter for energy metering PCGGIO - -
Event counter CNTGGIO - -
Supervision and monitoring
Runtime counter for machines and devices MDSOPT OPTS OPTM
Circuit breaker condition monitoring SSCBR CBCM CBCM
Fuse failure supervision SEQRFUF FUSEF 60
Current circuit supervision CCRDIF MCS 3I MCS 3I
Trip-circuit supervision TCSSCBR TCS TCM
Station battery supervision SPVNZBAT U<> U<>
Energy monitoring EPDMMTR E E
Measured value limit supervision MVEXP - -
Measurement
Three-phase current measurement CMMXU 3I 3I
Three-phase voltage measurement (phase-to-earth) VPHMMXU 3Upe 3Upe
Three-phase voltage measurement (phase-to-phase) VPPMMXU 3Upp 3Upp
Residual current measurement RESCMMXU I0 I0
Generator Protection and Control
1MRS757583 C
REG630
Product version: 1.3
ABB 67
