Table 126. Functions included in the relay, continued
Description IEC 61850 IEC 60617 ANSI
Residual voltage measurement RESVMMXU U0 U0
Power monitoring with P, Q, S, power factor, frequency PWRMMXU PQf PQf
Sequence current measurement CSMSQI I1, I2 I1, I2
Sequence voltage measurement VSMSQI U1, U2 V1, V2
Analog channels 1-10 (samples) A1RADR ACH1 ACH1
Analog channels 11-20 (samples) A2RADR ACH2 ACH2
Analog channels 21-30 (calc. val.) A3RADR ACH3 ACH3
Analog channels 31-40 (calc. val.) A4RADR ACH4 ACH4
Binary channels 1-16 B1RBDR BCH1 BCH1
Binary channels 17 -32 B2RBDR BCH2 BCH2
Binary channels 33 -48 B3RBDR BCH3 BCH3
Binary channels 49 -64 B4RBDR BCH4 BCH4
Station communication (GOOSE)
Binary receive GOOSEBINRCV - -
Double point receive GOOSEDPRCV - -
Interlock receive GOOSEINTLKRCV - -
Integer receive GOOSEINTRCV - -
Measured value receive GOOSEMVRCV - -
Single point receive GOOSESPRCV - -
Generator Protection and Control
1MRS757583 C
Product version: 1.3
68 ABB
