ABB ReliaGear LV SG E2.2 - Page 4

4
5
E2.2 - E4.2 - E6.2
© Copyright 2019-2020 ABB. All rights reserved.
www.abb.com
For more information please contact:
ABB S.p.A.
Via Pescaria, 5
24123 Bergamo - Italy
Phone: +39 035 395 111
dia. min. 1/4" / Ø min. 6,3 mm.
dia. max. 5/16" / Ø min. 8 mm.
1 TOP + 1 BOTTOM
E2.2
E4.2
E6.2
MINIMUM NUMBER OF LOCKS
E2.2 - E4.2 - E6.2
Example for E2.2 III
1 TOP LEFT + 1 BOTTOM LEFT
1 TOP RIGHT + 1 BOTTOM RIGHT
1 TOP + 1 BOTTOM
8,6 Nm
76 lb-in
D
F
A
1
4
2
2
1
3
CLACK!
