IEC61850 LN.DO.DA AFL-Common SA name IEC61850 LN Desc, DO Desc, DAName Value
LEDPTRC1.Op.phsC - Global conditioning, Operate, phsC 1 = Operate (phsC)
LEDPTRC1.Str.general - Global conditioning, Start, general 1 = Start (general)
LEDPTRC1.Str.phsA - Global conditioning, Start, phsA 1 = Start (phsA)
LEDPTRC1.Str.phsB - Global conditioning, Start, phsB 1 = Start (phsB)
LEDPTRC1.Str.phsC - Global conditioning, Start, phsC 1 = Start (phsC)
Local/remote (also present in IIN)
LLN0.Loc.stVal - Control LLN0, Local / remote, stVal 1 = Local
LLN0.Loc1.stVal - Control LLN0, Local / Off, stVal 1 = Off
Parameter settings supervision
LLN0.SetChg.stVal - General, Settings change, stVal 1 = Settings changed
LLN0.SetSeld.stVal - General, Settings reservation, stVal 1 = Settings reserved
Line differential protection with stabilized and inst. stages
LNPDIF1.Op.general LNPDIF1.OPERATE LNPLDF1, Operate, general 1 = Operate
LNPDIF1.Str.general LNPDIF1.START LNPLDF1, Start, general 1 = Start
Negative-sequence overcurrent protection signals (2 stages)
NSPTOC1.Op.general NSPTOC1.OPERATE NSPTOC1, Operate, general 1 = Operate
NSPTOC1.Str.general NSPTOC1.START NSPTOC1, Start, general 1 = Start
NSPTOC2.Op.general NSPTOC2.OPERATE NSPTOC2, Operate, general 1 = Operate
NSPTOC2.Str.general NSPTOC2.START NSPTOC2, Start, general 1 = Start
Protection communication supervision
PCSRTPC1.HealthAlm.stVal PCSRTPC1.ALARM PCSRTPC1, ALARM, stVal 1 = Alarm
Phase discontinuity protection, variants DE02,03
PDNSPTOC1.Op.general PDNSPTOC1.OPERATE PDNSPTOC1, Operate, general 1 = Operate
PDNSPTOC1.Str.general PDNSPTOC1.START PDNSPTOC1, Start, general 1 = Start
Phase overcurrent protection signals (3 stages)
PHHPTOC1.Op.general PHHPTOC1.OPERATE PHHPTOC1, Operate, general 1 = Operate
PHHPTOC1.Str.general PHHPTOC1.START PHHPTOC1, Start, general 1 = Start
PHHPTOC2.Op.general PHHPTOC2.OPERATE PHHPTOC2, Operate, general 1 = Operate
PHHPTOC2.Str.general PHHPTOC2.START PHHPTOC2, Start, general 1 = Start
PHIPTOC1.Op.general PHIPTOC1.OPERATE PHIPTOC1, Operate, general 1 = Operate
PHIPTOC1.Str.general PHIPTOC1.START PHIPTOC1, Start, general 1 = Start
PHLPTOC1.Op.general PHLPTOC1.OPERATE PHLPTOC1, Operate, general 1 = Operate
PHLPTOC1.Str.general PHLPTOC1.START PHLPTOC1, Start, general 1 = Start
Disturbance recorder
RDRE1.RcdMade.stVal - Disturbance recorder, Recording made, stVal 1 = Recording mede
Residual current limit supervision, variants DE02,03
RESCMMXU1.HiAlm.stVal RESCMMXU1.HIGH_ALARM RESCMMXU1, High alarm, stVal 1 = High alarm
RESCMMXU1.HiWrn.stVal RESCMMXU1.HIGH_WARING RESCMMXU1, High warning, stVal 1 = High warning
Residual voltage limit supervision, variant DE02
Table continues on next page
1MRS756879 A Section 2
DNP3 data mappings
RED615 13
Point List Manual
