IEC61850 LN.DO.DA AFL-Common SA name IEC61850 LN Desc, DO Desc, DAName Value RESVMMXU1.HiAlm.stVal RESVMMXU1.HIGH_ALARM RESVMMXU1, High alarm, stVal 1 = High alarm RESVMMXU1.HiWrn.stVal RESVMMXU1.HIGH_WARING RESVMMXU1, High warning, stVal 1 = High warning
Circuit breaker condition monitoring
SSCBR1.APwrAlm.stVal SSCBR1.IPOW_ALM SSCBR1, Accumulated currents power (Iyt),exceeded alarm limit, stVal 1 = Iyt alarm limit SSCBR1.APwrLO.stVal SSCBR1.IPOW_LO
SSCBR1, Accumulated currents power (Iyt),exceeded lockout limit, stVal 1 = Iyt lockout limit
SSCBR1.CBLifAlm.stVal SSCBR1.CB_LIFE_ALM SSCBR1, Remaining life of CB exceeded alarm limit, stVal 1 = Remaining life alarm SSCBR1.ClsAlm.stVal SSCBR1.TRV_T_CL_ALM SSCBR1, CB close travel time exceeded set value, stVal 1 = Close travel time alarm SSCBR1.LonTmAlm.stVal SSCBR1.MON_ALM SSCBR1, CB 'not operated for long time' alarm, stVal 1 = Not operated alarm SSCBR1.OpnAlm.stVal SSCBR1.TRV_T_OP_ALM SSCBR1, CB open travel time exceeded set value, stVal 1 = Open travel time alarm SSCBR1.OpNumAlm.stVal SSCBR1.OPR_ALM SSCBR1, Number of CB operations exceeds alarm limit, stVal 1 = CB operations alarm SSCBR1.OpNumLO.stVal SSCBR1.OPR_LO SSCBR1, Number of CB operations exceeds lockout limit, stVal 1 = CB operations lockout SSCBR1.PresAlm.stVal SSCBR1.PRES_ALM SSCBR1, Pressure below alarm level, stVal 1 = Low pressure alarm SSCBR1.PresLO.stVal SSCBR1.PRES_LO SSCBR1, Pressure below lockout level, stVal 1 = Low pressure lockout SSCBR1.SprChaAlm.stVal SSCBR1.SPR_CHR_ALM SSCBR1, Spring charging time has crossed the set value, stVal 1 = Spring charge alarm
Thermal overload protection, variants DE02,03
T1PTTR1.AlmThm.general T1PTTR1.ALARM T1PTTR1, Thermal Alarm, general 1 = Alarm T1PTTR1.Op.general T1PTTR1.OPERATE T1PTTR1, Operate, general 1 = Operate T1PTTR1.Str.general T1PTTR1.START T1PTTR1, Start, general 1 = Start
Trip circuit supervision
TCSSCBR1.CirAlm.stVal TCSSCBR1.ALARM TCSSCBR1, Alarm, stVal 1 = Alarm TCSSCBR2.CirAlm.stVal TCSSCBR2.ALARM TCSSCBR2, Alarm, stVal 1 = Alarm
Global conditioning
TRPPTRC1.Op.general - TRPPTRC1, Operate input signal, general 1 =Operate input TRPPTRC1.Tr.general - TRPPTRC1, General trip output signal, general 1 =Operate output TRPPTRC2.Op.general - TRPPTRC2, Operate input signal, general 1 =Operate input TRPPTRC2.Tr.general - TRPPTRC2, General trip output signal, general 1 =Operate output
Raw I/O signals
XGGIO100.SPCSO1.stVal - X100 (PSM), X100-Output 1, stVal 1 = ON, 0 = OFF XGGIO100.SPCSO2.stVal - X100 (PSM), X100-Output 2, stVal 1 = ON, 0 = OFF XGGIO100.SPCSO3.stVal - X100 (PSM), X100-Output 3, stVal 1 = ON, 0 = OFF XGGIO100.SPCSO4.stVal - X100 (PSM), X100-Output 4, stVal 1 = ON, 0 = OFF XGGIO100.SPCSO5.stVal - X100 (PSM), X100-Output 5, stVal 1 = ON, 0 = OFF XGGIO100.SPCSO6.stVal - X100 (PSM), X100-Output 6, stVal 1 = ON, 0 = OFF XGGIO110.Ind1.stVal - X110 (BIO), X110-Input 1, stVal 1 = ON, 0 = OFF XGGIO110.Ind2.stVal - X110 (BIO), X110-Input 2, stVal 1 = ON, 0 = OFF XGGIO110.Ind3.stVal - X110 (BIO), X110-Input 3, stVal 1 = ON, 0 = OFF XGGIO110.Ind4.stVal - X110 (BIO), X110-Input 4, stVal 1 = ON, 0 = OFF XGGIO110.Ind5.stVal - X110 (BIO), X110-Input 5, stVal 1 = ON, 0 = OFF XGGIO110.Ind6.stVal - X110 (BIO), X110-Input 6, stVal 1 = ON, 0 = OFF
Table continues on next page
Section 2 1MRS756879 A
DNP3 data mappings
14 RED615
Point List Manual
