Table 11. RTD inputs, continued
Description Value
mA inputs Supported current range -20 mA … +20 mA
Current input impedance 100 Ω ± 0.1%
Operation accuracy ± 0.1% ± 20 ppm per °C of full-
scale
Ambient
temperature
-40°C to 70°C
Voltage
inputs
Supported voltage range -10 V DC….+10 V DC
Operation accuracy ±0.1% ± 40 ppm per °C of full-
scale
Ambient
temperature
-40°C to 70°C
Table 12. Signal output and IRF output
IRF relay change over - type signal output relay
Description Value
Rated voltage 250 V AC/DC
Continuous contact carry 5 A
Make and carry for 3.0 s 10 A
Make and carry 0.5 s 15 A
Breaking capacity when the control-circuit
time constant L/R<40 ms, at U< 48/110/220
V DC
≤0.5 A/≤0.1 A/≤0.04 A
Minimum contact load 100 mA at 24 V AC/DC
Table 13. Power output relays without TCS function
Description Value
Rated voltage 250 V AC/DC
Continuous contact carry 8 A
Make and carry for 3.0 s 15 A
Make and carry for 0.5 s 30 A
Breaking capacity when the control-circuit
time constant L/R<40 ms, at U< 48/110/220
V DC
≤1 A/≤0.3 A/≤0.1 A
Minimum contact load 100 mA at 24 V AC/DC
Motor Protection and Control 1MRS756977 D
REM630
Product version: 1.1 Issued: 2011-05-18
20 ABB
