Table 105. Functions included in REM630, continued
Functionality IEC 61850 IEC 60617 ANSI
Fuse failure supervision SEQRFUF FUSEF 60
Current circuit supervision CCRDIF MCS 3I MCS 3I
Trip circuit supervision TCSSCBR TCS TCM
Station battery supervision SPVNZBAT U<> U<>
Energy monitoring EPDMMTR E E
Measured value limit supervision MVEXP
Measurement
Three-phase current CMMXU 3I 3I
Three-phase voltage (phase-to-
earth)
VPHMMXU 3Upe 3Upe
Three phase voltage (phase-to-
phase)
VPPMMXU 3Upp 3Upp
Residual current RESCMMXU I0 I0
Residual voltage RESVMMXU U0 Vn
Sequence current CSMSQI I1, I2 I1, I2
Sequence voltage VSMSQI U1, U2 V1, V2
Power monitoring with P, Q, S,
power factor, frequency
PWRMMXU PQf PQf
Disturbance recorder function
Analog channels 1-10 (samples) A1RADR ACH1 ACH1
Analog channels 11-20 (samples) A2RADR ACH2 ACH2
Analog channels 21-30 (calc. val.) A3RADR ACH3 ACH3
Analog channels 31-40 (calc. val.) A4RADR ACH4 ACH4
Binary channels 1-16 B1RBDR BCH1 BCH1
Binary channels 17-32 B2RBDR BCH2 BCH2
Binary channels 33-48 B3RBDR BCH3 BCH3
Binary channels 49-64 B4RBDR BCH4 BCH4
Station communication (GOOSE)
Binary receive GOOSEBINRCV
Double point receive GOOSEDPRCV
Interlock receive GOOSEINTLKRCV
Motor Protection and Control 1MRS756977 D
REM630
Product version: 1.1 Issued: 2011-05-18
72 ABB
