ABB RER620 - Page 43

1MAC302441-MB A Section 2
IEC 60870-5-101/104 data mappings
RER620 37
Point List Manual
Table 5: Integrated totals and regulating step positions
No events 61850 Path IOA Disabled Description Multiplier Interrogation
PEMMTR1.SupWh.actVal 14000 Reverse active energy Wh
PEMMTR1.SupVArh.actVal 14001 Reverse reactive energy VArh
PEMMTR1.DmdWh.actVal 14002 Forward active energy Wh
PEMMTR1.DmdVArh.actVal 14003 Forward reactive energy VArh
