ABB REU615 - LD0.XAGGIO130 Physical I;O States (AIM Card XA130); LD0.MVGAPC1 Multipurpose Binary Inputs (1)

2.3.1.69 LD0.XAGGIO130 Physical I/O states (AIM card XA130)
Table 72: LD0.XAGGIO130 Physical I/O states (AIM card XA130)
BitA RegA IEC 61850 name SA name Description Values
LD0.XAGGIO130
3264 204.00 .Ind1.stVal XA130-Input 1 State 0/1=Off/On
3265 204.01 .mcd
3266 204.02 .Ind2.stVal XA130-Input 2 State 0/1=Off/On
3267 204.03 .mcd
3268 204.04 .Ind3.stVal XA130-Input 3 State 0/1=Off/On
3269 204.05 .mcd
3270 204.06 .Ind4.stVal XA130-Input 4 State 0/1=Off/On
3271 204.07 .mcd
2.3.1.70 LD0.MVGAPC1 Multipurpose binary inputs (1)
Table 73: LD0.MVGAPC1 Multipurpose binary inputs (1)
BitA RegA IEC 61850 name SA name Description Values
LD0.MVGAPC1
3536 221.00 .Q1.stVal Input 1 0/1=Off/On
3537 221.01 .mcd
3538 221.02 .Q2.stVal Input 2 0/1=Off/On
3539 221.03 .mcd
3540 221.04 .Q3.stVal Input 3 0/1=Off/On
3541 221.05 .mcd
3542 221.06 .Q4.stVal Input 4 0/1=Off/On
3543 221.07 .mcd
3544 221.08 .Q5.stVal Input 5 0/1=Off/On
3545 221.09 .mcd
3546 221.10 .Q6.stVal Input 6 0/1=Off/On
3547 221.11 .mcd
3548 221.12 .Q7.stVal Input 7 0/1=Off/On
3549 221.13 .mcd
3550 221.14 .Q8.stVal Input 8 0/1=Off/On
3551 221.15 .mcd
1MRS757057 B Section 2
Modbus data mappings
REU615 41
Point List Manual
