RegA Typ Scale IEC 61580 name SA name Description Values
9228.0 Bit - bit 0 1=Cold start
9228.1 Bit - bit 1 1=Watchdog
9228.2 Bit - bit 2 1=Warm start
2.3.2.42 Active parameter setting group - read and write
Table 118: Active parameter setting group - read and write
RegA Typ Scale IEC 61580 name SA name Description Values
9231 u16 1 Active setting group 1..6
2.3.2.43 Event record structure
Table 119: Event record structure
RegA Typ Scale IEC 61580 name SA name Description Values
Selection write:
9250 u16 1 - Num of multiple records 1..10
9251 i16 1 - Read selection -499…3
Record 1 data to read:
9252 u16 1 - Record sequence num 1..9999
9253 u16 1 - Unread records left 0..499
Timestamp of record
9254 u16 1 - Year, Month Year/Month
9255 u16 1 - Day, Hour Day/Hour
9256 u16 1 - Minute, Second Min/Sec
9257 u16 1 - Millisecond Millisecond
9258 u16 1 Event identification see doc.
9259 u16 1 Data object ID1 see doc.
9260 u16 1 Data object ID2 see doc.
9261 u16 1 Event data value 1 see doc.
9262 u16 1 Event data value 2 see doc.
Record 2 data to read: If selected
9263 u16 1 - Record sequence num 1..9999
9264 u16 1 - Unread records left 0..499
Timestamp of record
9265 u16 1 - Year, Month Year/Month
9266 u16 1 - Day, Hour Day/Hour
9267 u16 1 - Minute, Second Min/Sec
Table continues on next page
1MRS757057 B Section 2
Modbus data mappings
REU615 59
Point List Manual
