2.3.3.10 LD0.SRGAPC2 Reset SRGAPC2 generic flip-flops
Table 132: LD0.SRGAPC2 Reset SRGAPC2 generic flip-flops
0xA CS IEC 61580 name SA name Description Values
LD0.SRGAPC2
2104 4.08 .Rs1.Oper.ctlVal Reset flip-flop 1 1=Reset
2105 4.09 .Rs2.Oper.ctlVal Reset flip-flop 2 1=Reset
2106 4.10 .Rs3.Oper.ctlVal Reset flip-flop 3 1=Reset
2107 4.11 .Rs4.Oper.ctlVal Reset flip-flop 4 1=Reset
2108 4.12 .Rs5.Oper.ctlVal Reset flip-flop 5 1=Reset
2109 4.13 .Rs6.Oper.ctlVal Reset flip-flop 6 1=Reset
2110 4.14 .Rs7.Oper.ctlVal Reset flip-flop 7 1=Reset
2111 4.15 .Rs8.Oper.ctlVal Reset flip-flop 8 1=Reset
2.3.3.11 LD0.SPCGGIO1 Multipurpose binary outputs (1)
The binary outputs may be configured either as pulse- or persistent-type outputs.
Pulse-type outputs are triggered with the write value "1". Persistent-type outputs
can be written with both "1" and "0" values. The persistent type is the same as the
toggled mode on LHMI and WHMI.
Table 133: LD0.SPCGGIO1 Multipurpose binary outputs (1)
0xA
CS IEC 61580 name SA name Description Values
LD0.SPCGGIO1
2112 5.00 .SPCS01.ctlVal Output 1 control 0/1=Off/On
2113 5.01 .SPCS02.ctlVal Output 2 control 0/1=Off/On
2114 5.02 .SPCS03.ctlVal Output 3 control 0/1=Off/On
2115 5.03 .SPCS04.ctlVal Output 4 control 0/1=Off/On
2116 5.04 .SPCS05.ctlVal Output 5 control 0/1=Off/On
2117 5.05 .SPCS06.ctlVal Output 6 control 0/1=Off/On
2118 5.06 .SPCS07.ctlVal Output 7 control 0/1=Off/On
2119 5.07 .SPCS08.ctlVal Output 8 control 0/1=Off/On
2120 5.08 .SPCS09.ctlVal Output 9 control 0/1=Off/On
2121 5.09 .SPCS10.ctlVal Output 10 control 0/1=Off/On
2122 5.10 .SPCS11.ctlVal Output 11 control 0/1=Off/On
2123 5.11 .SPCS12.ctlVal Output 12 control 0/1=Off/On
2124 5.12 .SPCS13.ctlVal Output 13 control 0/1=Off/On
2125 5.13 .SPCS14.ctlVal Output 14 control 0/1=Off/On
2126 5.14 .SPCS15.ctlVal Output 15 control 0/1=Off/On
2127 5.15 .SPCS16.ctlVal Output 16 control 0/1=Off/On
Section 2 1MRS757057 B
Modbus data mappings
68 REU615
Point List Manual
