V2 S500 Hardware 1-12 System Data S500 / Issued: 01.2007
AX522 DX522
Internal error on the processor card of the FBP Interface ModuleSituation:
PWR FBP S-ERR I/O-Bus UP CH-ERR1 CH-ERR2 UP CH-ERR2 CH-ERR4 UP CH-ERR1 CH-ERR2
DC505-FBP AX522 DX522
DC505 DI524
UP CH-ERR1 CH-ERR2 CH-ERR3 CH-ERR4
DI524
No function at all, the I/O-Bus turns to the reset status or gets the replacement values
UP CH-ERR1 CH-ERR2 CH-ERR3 CH-ERR4
DC532
DC532
All modules OK, but there is an overload or short-circuit at oneSituation:
Everything is still running, but an error message is sent to the fieldbus master
output of the FBP Interface Module DC505-FBP
All modules OK, but there is an overload or short-circuit at oneSituation:
output of an I/O expansion module
Internal error on the I/O card of the FBP Interface ModuleSituation:
UP is present at all modules,
FBP is plugged
Internal error on the I/O card of an I/O expansion moduleSituation:
All modules OK, but there is a broken wire at an analog outputSituation:
A wrong parameter was sent to a moduleSituation:
An error message is sent to the fieldbus master
LEDs:
LED OFF
green LED ON
green LED flashes
red LED ON
red LED flashes
No function at all, the I/O-Bus turns to the reset status or gets the replacement values
No function at all, the I/O-Bus turns to the reset status or gets the replacement values
Everything is still running, but an error message is sent to the fieldbus master
Everything is still running, but an error message is sent to the fieldbus master
Figure: Displays in case of different errors
