17
The measures required for entering a submenu
or a setting mode and how to perform the set-
ting and use the TEST mode are described in
detail on data sheet "General characteristics of
the D-type plug-in units". Below a short guide.
Desired step or operation Push-button Action
Forward step in main or submenu STEP Press > 0.5 s
Rapid scan forward in main menu STEP Keep depressed
Reverse step in main or submenu STEP Press < 0.5 s
Entering a submenu from the mainmenu PROGRAM Press 1 s
Entering or leaving setting mode PROGRAM Press for 5 s
Increasing a value in setting mode STEP
Moving the cursor in setting mode PROGRAM Press about 1 s
Storing a value in setting mode STEP & PROGRAM Press simultaneously
Resetting memorized values + output relays STEP & PROGRAM
Resetting of latched output relays PROGRAM Note!
Display must be off
