Table 15 - Parts for TA0107L through TA5215H Taper Bushed and Single Reduction Reducers
Ref. Description Quantity TA0107L TA1107H TA2115H TA3203H TA4207H TA5215H
40 First Stage Gear Key 1 900276 901276 902276 903276 904276 905276
41
Countershaft Bearing Shim-As
Required
.015” Shim
.007” Shim
.005” Shim
900271
900273
900278
901271A
901273A
901272A
901271
901273
901272
903267
903269
903268
903267
903269
903268
905271
905272
905273
44 Auxiliary Output Seal 2 900236 901236 902236 903236 904236 905236
45 Auxiliary Input Seal
5:1, 9:1, 15:1, 25:1 Ratio ③
40:1 Ratio ③
1
1
442023
442023
442023
442023
902238
442023
903238
N/A
904238
904238
905238
905238
100 ⑤Torque-Arm Adapter Bracket 2 900500P 901500P 902500P 903500P 904500P 905500P
Torque-Arm Rod Kit ④ 1 964263 964263 A73091 A73091 964268 964268
101 ⑤ Torque-Arm Rod End ⑥ 1 A73092 A73092 A73087 A73087 A73146 A73146
102 ⑤ Torque-Arm Extension ⑥ 1 A73085 A73092 A73088 A73088 A73092 A73092
103 ⑤ Torque-Arm Turnbuckle ⑥ 1 A73086 A73086 A73089 A73089 A73148 A73148
104 ⑤ RH Nut ⑥ 1 407122 407122 407095 407095 033102022AB 033102022AB
105 ⑤ LH Nut ⑥ 1 A73261 A73261 407244 407244 A73263 A73263
106 Torque-Arm Bushing 1 242243 242243 243243 243243 245243 245243
107 Torque-Arm Fulcrum 1 241249 241249 243249 243249 246249 246249
108 Torque-Arm Bolt 1 411412 411412 411437 411437 411460 411460
109 Torque-Arm Lockwasher 1 419011 419011 419012 419012 419013 419013
110 Torque-Arm Nut 1 407087 407087 407089 407089 407091 407091
111 Torque-Arm Bolt 1 411456 411456 032018016EJ 032018016EJ 032018016EJ 032018016EJ
112 Torque-Arm Nut 1 407091 407091 407093 407093 407093 407093
113 Lockwasher 1 N/A N/A N/A N/A N/A N/A
200 Bushing Back-Up Plate 2 241266 901301 243308 903301 904301 905301
203 Retaining Ring 2 421111 901304 421109 903304 421107 421055
204 Bushing Cap Screw 6 411405 411390 902306 032018010CJ 032018010CJ 411456
205 Bushing Lockwasher 6 419010 419010 419011 419011 419011 419013
④ Adapter & Hardware Kit 1 900070 901070 902070 903070 904070 905070
400 ⑤ Screw Conveyor Adapter 1 900401 901401 902401 903401 904401 905401
401 ⑤ Screw Conveyor Keeper Plate 1 900402 901402 902402 903402 904402 905402
402 ⑤ Screw Conveyor Wedge 1 900403 901403 902403 903403 904403 905403
403 Screw Conveyor Drive Shaft
1-1/2” Shaft
1-1/2” Shaft, Stainless Steel
2” Shaft
2” Shaft, Stainless Steel
2-7/16” Shaft
2-7/16” Shaft, Stainless Steel
3” Shaft
3” Shaft, Stainless Steel
3-7/16” Shaft
3-7/16” Shaft, Stainless Steel
1
1
1
1
1
1
1
1
1
1
900072
900080
900073
900081
900074
900082
900075
900083
N/A
N/A
901072
901080
901073
901081
901074
901082
901075
901083
N/A
N/A
902072
902080
902073
902081
902074
902082
902075
902083
902076
902084
N/A
N/A
903073
903081
903074
903082
903075
903083
903076
903084
N/A
N/A
904073
904081
904074
904082
904075
904083
904073
904084
N/A
N/A
9050732
905081
905074
905082
905075
905083
905076
905084
404 ⑤ Retaining Bolt 1 411549 411549 411549 411551 411551 411551
405 ⑤ Lockwasher 1 034017018AB 034017018AB 034017018AB 034017020AB 034017020AB 034017020AB
406 ⑤ Drive Shaft Key 1 900405 901405 902405 903405 904405 905405
407 ⑤ Drive Shaft Washer 1 900404 901404 902404 903404 904404 905404
408 ⑤ Seal 2 900411 901411 902411 353085 904411 905411
409 ⑤ Bolt 4 032018012CJ 032018012CJ 411435 411456 411456 411483
410 ⑤ Lockwasher 4 419011 419011 419012 419013 419013 034017018AB
411 ⑤ Retaining Ring 1 900446 901446 902446 903446 904446 905446
412 Adjustable Packing Retainer 1 900413 901413 902413 903413 904413 905413
413 Adjustable Packing Gland Stud 2 400404 400404 400404 400404 400404 400404
414 Adjustable Packing Gland Nut 2 407202 407202 407202 407202 407202 407202
415 Sealing Rings 3 900416 901416 902416 903416 904416 905416
600 Backstop Assembly
5:1, 9:1, 15:1, 25:1 Ratio ③ 1 901102 901102 902102 903102 904102 905102
40:1 Ratio ③ 1 901102 901102 902102 903102 904103 905103
NOTES:
① Not shown on drawing.
② 8 required on TA5215H
③ See Table 14 for actual ratio
④ Includes parts listed immediately below marked ⑤
⑤ Makes up assembly under which it is listed marked ④
⑥ Zinc plated as of 2016.
