Operation Manual / TPL67-C.. - TPL71-C..
Cleaning the filter silencer
Page 55
© Copyright 2017 ABB. All rights reserved.
February 2017 HZTL2488_EN Revision D
Join connecting rods (81269) using screws (81272). When tightening
the screws (81272), ensure that connecting rods (81269) are located
correctly in recesses in filter silencer body (81135). Now tighten
screws (81272) alternately until the following maximum torque is
reached:
81272 20
Screw lock nuts (81273) onto screw (81272) and tighten to following
torque:
81273 40
Fit filter strip (81265).
