 Measure and note the axial clearance (
A
) (see the section on axial
clearance).
CAUTION
If the axial clearance (A) is out of tolerance, an ABB Turbocharger ser-
vice station must be contacted.
 Connect oil pipes and all air lines in accordance with enginebuilder
specifications.
Version with compressor wheel cooling system
 Fit the air supply line. (See also chapter entitled Preliminary remarks /
Layout and functionality)
 Fit the filter silencer or air suction branch.
 Fit the insulation.
