Operation Manual / TPL69-A10 / -A30 ... TPL77-A10 / -A30
8 Disassembly and assembly / 8.9 Table of tightening torques
© Copyright 2018 . All rights reserved. HZTL2481_EN Revision C May 2018
Tightening torques [Nm]
Item Part number TPL69-A TPL73-A TPL77-A
01 82005 M16x1.5
45
M16x1.5
45
M16x1.5
45
03
1)
76002 M12 M14 M16
04 74027
With washer
M16
125
M18
170
M20
220
05 61036
74026/74029
M16
30
M18
80
M20
80
06 61044
61056
61059
M16
260
M18
370
M20
480
06b 61077
If provided
M16
20
- - - -
07 42059
42064
M16
105
M16
105
M20
240
10 61037 M16
105
M18
160
M20
210
11 61090 M16
10
M18
15
M20
20
14 86505 M18x1.5
150
M18x1.5
150
M18x1.5
150
21 90458 M8
20
M10
30
M10
30
1)
Tighten the screw (76002) as far as it will go and then un-
screw it by ¼ turn. The screw must be loose and the diffuser
must be movable.
Page 115 / 136
