Operation Manual / TPL69-A10 / -A30 ... TPL77-A10 / -A30
12 Spare parts / 12.1 Ordering spare parts
© Copyright 2018 . All rights reserved. HZTL2481_EN Revision C May 2018
TPL73-A
Quantity Description Part number
2 Hexagon-head screw 42059/42064
2 Verbus Ripp® washer 42058/42063
15 Hexagon-head screw 61044/61056/61059
15 Verbus Ripp® washer 61043/61057/61058
3 Hexagon nut 61037
1 Gasket 42041
2 Gasket 42045
2 O-ring 42012/76040
2 O-ring 77005/77006
1 O-ring 86506
TPL77-A
Quantity Description Part number
15 Hexagon-head screw 42059/42064/61044/61056/61059
15 Verbus Ripp® washer 42058/42063/61043/61057/61058
3 Hexagon nut 61037
1 Gasket 42041
2 Gasket 42045
2 O-ring 42012/76040
2 O-ring 77005/77006
1 O-ring 86506
TPL77-A Version with
compressor wheel cooling
Quantity Description Part number
15 Hexagon-head screw 42059/42064/61044/61056/61059
15 Verbus Ripp® washer 42058/42063/61043/61057/61058
3 Hexagon nut 61037
1 Gasket 42041
2 Gasket 42045
2 O-ring 42012/76040
1 O-ring 42124
2 O-ring 77005/77006
1 O-ring 86506
Page 132 / 136
