Operation Manual / TPL69-A10 / -A30 ... TPL77-A10 / -A30
12 Spare parts / 12.2 View of turbocharger with part numbers
© Copyright 2018 . All rights reserved. HZTL2481_EN Revision C May 2018
Part number Description
10900 Cartridge group
42012 (in customer spare part
set)
O-ring
42124 (in customer spare part
set)
O-ring (option with compressor wheel cool-
ing)
51001 Gas inlet casing
56001 Nozzle ring
61001 Gas outlet casing
61036 Stud
61043 (in customer spare part
set)
Verbus Ripp® Washer
61044 (in customer spare part
set)
Hexagon-head screw
61050 (if provided) Gasket
61056 (in customer spare part
set)
Hexagon-head screw
61057 (in customer spare part
set)
Verbus Ripp® Washer
61058 (in customer spare part
set)
Verbus Ripp® Washer
61059 (in customer spare part
set)
Hexagon-head screw
61037 (in customer spare part
set)
Hexagon nut
610
76
1)
(if present) Centering bolt
61077
1)
(if present) Hexagon nut
63000 Turbine diffuser
68000 Foot
74018 Washer
74026 / 74029 Stud
74027 Hexagon nut
74000 Compressor casing external part
76000 Compressor casing internal part
76040 (in customer spare part
set)
O-ring
76080 Safety segment
77000 Wall insert
77005 (in customer spare part
set)
O-ring
77006 (in customer spare part
set)
O-ring
79000 Diffuser
81000 Filter silencer
82000 Radial air suction branch
82000 Axial air suction branch
1)
TPL69-A only
Page 135 / 136
