ABB TPU 40.21 - Dimensional Drawings TJE

36
CURRENT AND VOLTAGE INSTRUMENT TRANSFORMERS
INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE
202
103
94
38
28
26
M8
M10
Pg16 14
120
190
4
70
155
4x 8,5
253
85 70
30
106 107
15
12
120
Drawing n.
1VL4200252R0101
TJE 3
TJE 4
WEIGHT: 10kg
CREEPAGE DISTANCE: 245mm

202
103
94
4
28
38
54
M8
M10
Pg16
14
120
190
70
125 125 148
2x
11
11
145125
107
11
270 11 10
338
Drawing n.
1VL4200271R0101
TJE 3.1
TJE 4.1
WEIGHT: 11,5kg
CREEPAGE DISTANCE: 245mm

Dimensional Drawings TJE
—
TJE 3
TJE 4
—
TJE 3.1
TJE 4.1

Creepage distance: 245 mm

Creepage distance: 245 mm
