ABB TPU Series User Manual

20
CURRENT AND VOLTAGE INSTRUMENT TRANSFORMERS
INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE
Appendix 6
Dimensional Drawing TPU 4x.xx and TPU 5x.xx
220
b
a
12
C
B
F
D
G
E
H
80
40
32 120
20
M12
TPU 4(5)0.11, TPU 4(5)3.11
TPU 4(5)0.21, TPU 4(5)3.21
68
60
32 120
18
M12
TPU 4(5)0(3).1(2)3
TPU 4(5)0(3).31(3)
TPU 4(5)0(1,2,3).41(3)
TPU 4(5)0(3).53
80
40
32 120
33,5
23 23 23
M12
M8
TPU 4(5)0.12, TPU 4(5)0.14
TPU 4(5)0.22, TPU 4(5)0.24
80
80
32 120
40
20
M12
TPU 4(5)4.1(2,3,4)1(3)
TPU 4(5)5.1(2,3,4)1(3)
TPU 4(5)6.1(2,3,4)1(3)
TPU 4(5)7.1(2,3,4)1(3)
TPU 4(5)8.1(2,3,4)1(3)
TPU 4(5)0(3).11 TPU 4(5)0.12 TPU 4(5)4(5,6,7,8).11 TPU 4(5)0(3).13 TPU 4(5)0.14 TPU 4(5)4(5,6,7,8).13 TPU 4(5)0(3).21 TPU 4(5)0.22 TPU 4(5)4(5,6,7,8).21 TPU 4(5)0(3).23 TPU 4(5)0.24 TPU 4(5)4(5,6,7,8).23 TPU 4(5)0(3).31 TPU 4(5)4(5,6,7,8).31 TPU 4(5)0(3).33 TPU 4(5)4(5,6,7,8).33 TPU 4(5)0.53 TPU 4(5)0(1,3).41 TPU 4(5)4(5,6,7,8).41 TPU 4(5)0(1,3).43 TPU 4(5)4(5,6,7,8).43
a [mm]
- 340 - 248 - 280 248 - 280
B [mm]
355 355 455 455 355 355 335 465 465
b [mm]
266 266 386 386 285 285 283 395 395
C [mm]
148 148 148 148 184 184 148 184 184
D [mm]
270 270 390 390 270 270 270 390 390
E [mm]
125 125 125 125 160 160 125 160 160
F [mm]
15 15 15 15 25 25 15 15 15
G [mm]
135 135 255 255 135 135 135 255 255
H [mm]
- 86 - 86 - 110 86 - 110
