Capacitive voltage indicator (divider)
The transformer can be supplied with the capaci-
tive voltage indicator on the request. Integrated
voltage detection system is corresponding to Sep-
arable Voltage Detection System according to IEC
61234-5. It is integrated coupling electrode con-
nected to secondary terminal (terminal Ck). Elec-
trode acts as a capacitor between electrode and
primary winding (C1), or electrode and ground
(C2). If the electrode is connected to indication de-
vice (not part of delivery – it is part of switchgear)
it works as indication of voltage presence – more
in IEC 61234-5.
Ub (kV)
Tab. 3. CE capacity according to nominal voltage
Note: Recommended min. capacities for nominal
voltage.
The fuse can be a part of a supply of voltage trans-
formers with fuse. We can supply following fuses:
Rated
current (A)
Rated voltage
(kV)
(mm)
Striker pin
Warning: All VT’s type TJP 4.0; TJPH 4.0; TJP 5.0;
TJPH 5.0; TJP 6.0, have fuse contact equipped
for transportation. Before installation must be
External fuse holder
external fuse holder and It can be installed in any
4. Instructions for use
Current and Voltage instrument transformers are
used:
•
• to insulate primary and secondary circuit from
each other to protect the secondary equipment
age appearing during the operation (short cir
—
fixation
—
—
10
—
11
