ABB twa-2 - Locking; Dimensions

11
4
th
pressure: temporary override 30 minutes. On, and 30 are permanent.
The return to automatic mode will take place after 30 min.
5
th
pressure: temporary override 60 minutes. On, and 60 are permanent.
The return to automatic mode will take place after 60 min.
6
th
pressure: permanent override. Off, and are permanent. This override
must be cancelled manually.
7
th
pressure: return to the automatic mode.
Locking
To prevent all undesirable actions, the keyboard of the time switch may be
locked using a key DT-LK.
Unlocking is done in the same way.
Full product reset remains feasible when the keyboard is locked.
Dimensions
1
23 4
5
67
8
85
35,8
60
52
43,8
45
