23
1ZSE 5492-118 en, Rev. 4
A
A
fm_00012
3 Installation in the transformer
Fig. 12.
Cover
Bevel gear
Top cover
Driving pin
Hose clipProtective tube
Screw M6
Coupling half
A
Guiding pin
Driving disc
View A - A
Key
