Step 1: Attach rear foot (without wheels) to rear of curved track.
Remove the 2 bolts which have been pre-attached to the rear foot,
then re-attach the bolts to connect foot
to track. Finger tighten bolts only.
Do not tighten bolts with tool until
unit is fully assembled.
Step 2: Attach front foot (with
wheels) to front post using the
2 pre-attached bolts. Finger
tighten only.
ASSEMBLY INSTRUCTIONS
IMPORTANT
: Remove all parts from packing and inspect for damage. Retain packing materials if possible.
SEAT
FRONT POST
CURVED
TRACK
REAR
FOOT
FRONT
FOOT
ARMREST
CONSOLE
Your Ab Coaster
®
has been thoroughly inspected and partly assembled before shipment.
You will need to take a few additional steps as described below to complete assembly.
If you have any questions, please call our customer service center at 973-287-5100.
Step 1: Attach Rear Foot
Step 2: Attach Front Foot
Step 3: Attach Front Post
Step 4: Attach Armrest Console
Step 5: Connect Wires
4
