A-80 UHF SERVICE MANUAL
- 12 -
29 51K 0603 ±5% 1 R410
30 68K 0603 ±5% 1 R10
31 82K 0603 ±5% 1 R135
32 100K 0402 ±5% 1 R245
33 100K 0603 ±5% 10
R31 R38 R41 R43
R44 R49
R50 R51 R139
R425
34 120K 0603 ±5% 1 R132
35 150K 0603 ±5% 7
R37 R239 R240
R241 R242
R243 R249
36 180K 0603 ±5% 1 R248
37 270K 0603 ±1% 1 R56
38 750K 0603 ±5% 1 R422
39 1M 0402 ±5% 1 R246
40 1M 0603 ±5% 1 R9
41 1.8M 0603 ±5% 2 R403 R406
42
NC
0603 1
R414
Resistor Network
43 1K×4 4×0603 YC164-JR-071K 3 CP1 CP2 CP4
44 100K×4 4×0603 YC164-JR-07100K 1 CP3
Adjustable Resistor
45 47K φ3 EVM3YSX50BQ4 1 VR400
46 220K φ3 EVM3YSX50BE5 2 VR100 VR101
Chip Capacitance
47 5PF 0402 COG，±0.1PF，50V 1 C344
48 10PF 0402 COG，±0.5PF，50V 1 C406
49 20PF 0402 COG，±5%，50V 1 C345
50 22PF 0402 COG，±5%，50V 2 C7 C8
51 100PF 0402 COG，±5%，50V 4
C29 C30 C246
C247
52 220PF 0402 COG，±5%，50V 3 C18 C23 C36
53 470PF 0402 X5R，±10%，16V 13
C34 C35 C40 C41
C43 C52
C53 C241 C249
C250 C252 C415
C416
54 470PF 0603 X5R，±10%，16V 1 C251
55 560PF 0402 X5R，±10%，16V 1 C421
56 680PF 0402 X5R，±10%，16V 2 C413 C414
57 1000PF 0402 X5R，±10%，16V 1 C420
