A-80 UHF SERVICE MANUAL
- 11 -
PARTS LIST
A-80（D03）ABOM
Ref.
No.
Specification Package Description Quantity Part No.
Chip Resistor
1 0R 0402 ±5% 1 R244
2 0R 0603 ±5% 4 R24 R26 R27 R28
3 0.39R 1206 ±5% 3 R236 R237 R238
4 10R 0603 ±5% 1 R1
5 100R 0603 ±5% 1 R449
6 330R 0603 ±5% 3 R5 R6 R16
7 390R 0603 ±5% 1 R253
8 470R 0603 ±5% 1 R413
9 680R 0402 ±5% 2 R232 R233
10 820R 0603 ±5% 1 R424
11 1K 0603 ±5% 10
R7 R8 R12 R17
R22 R30
R32 R34 R48
R401
12 1.5K 0603 ±5% 1 R421
13 2K 0603 ±5% 1 R420
14 2.2K 0603 ±5% 2 R60 R419
15 3.3K 0603 ±5% 2 R252 R402
16 4.7K 0603 ±5% 7
R11 R13 R14 R15
R39 R54 R61
17 5.6K 0603 ±5% 2 R247 R415
18 6.8K 0603 ±5% 2 R55 R409
19 10K 0402 ±5% 2 R231 R234
20 10K 0603 ±5% 6
R33 R35 R47 R59
R417 R418
21 15K 0603 ±5% 2 R411 R412
22 18K 0603 ±5% 1 R423
23 20K 0603 ±5% 1 R29
24 22K 0603 ±5% 1 R400
25 27K 0603 ±5% 1
R136
26 33K 0603 ±5% 4
R404 R405 R407
R408
27 47K 0402 ±5% 1 R235
28 47K 0603 ±5% 4
R40 R57 R131
R134
