A-80 UHF SERVICE MANUAL
- 15 -
2 0R 0805 ±5% 1 L301
3 0R 0603 ±5% 11
R112 R129 R140 R206 R304
R308 R309 R310 R311 R436
R440
4 0R 0805 ±5% 2 R201 R203
5 10R 0603 ±5% 5 R2 R103 R117 R216 R416
6 22R 0603 ±5% 3 R218 R222 R322
7 47R 0603 ±5% 3 R100 R200 R202
8 100R 0603 ±5% 3 R114 R301 R335
9 150R 0603 ±5% 2 R18 R314
10 220R 0603 ±5% 2 R312 R323
11 270R 0603 ±5% 5 R121 R125 R204 R205 R300
12 330R 0603 ±5% 4 R102 R130 R217 R221
13 470R 0603 ±5% 1 R329
14 560R 0603 ±5% 2 R106 R108
15 680R 0603 ±5% 2 R123 R220
16 1K 0603 ±5% 5 R107 R127 R224 R313 R426
17 1K 0603 ±1% 1 R448
18 1.2K 0603 ±5% 2 R128 R331
19 1.5K 0603 ±5% 1 R219
20 1.8K 0603 ±5% 3 R338 R339 R427
21 1.8K 0603 ±1% 1 R442
22 2.2K 0603 ±5% 2 R20 R111
23 2.7K 0603 ±5% 1
R109
24 3.3K 0603 ±5% 5 R105 R124 R305 R332 R334
25 3.9K 0603 ±5% 1 R321
26 4.7K 0402 ±5% 1 C425
27 4.7K 0603 ±5% 2 R25 R137
28 5.6K 0402 ±5% 1 C426
29 5.6K 0603 ±5% 4 R434 R450 R451 R454
30 6.8K 0603 ±5% 1 R101
31 8.2K 0603 ±5% 1 R119
32 10K 0603 ±5% 4 R19 R104 R110 R207
33 10K 0603 ±1% 1 R441
34 18K 0603 ±5% 1 R210
35 22K 0603 ±5% 1 R433
36 33K 0603 ±5% 1 R3
37 47K 0603 ±5% 5 R4 R118 R126 R208 R223
38 51K 0603 ±5% 2 R211 R333
39 56K 0603 ±5% 1 R23
40 68K 0603 ±5% 0
