A-80 UHF SERVICE MANUAL
- 22 -
52 220PF 0402 COG，±5%，50V 3 C18 C23 C36
53 470PF 0402 X5R，±10%，16V 13
C34 C35 C40 C41 C43 C52
C53 C241 C249
C250 C252 C415 C416
54 470PF 0603 X5R，±10%，16V 1 C251
55 560PF 0402 X5R，±10%，16V 1 C421
56 680PF 0402 X5R，±10%，16V 2 C413 C414
57 1000PF 0402 X5R，±10%，16V 1 C420
58 1000PF 0603 X5R，±10%，16V 1 C248
59 3300PF 0402 X5R，±10%，16V 2 C401 C403
60 3900PF 0402 X5R，±10%，16V 1 C9
61 0.01UF 0402 X5R，±10%，16V 8
C1 C4 C47 C48 C50 C51
C404 C412
62 0.022UF 0402 X5R，±10%，16V 2 C408 C417
63 0.027UF 0402 X5R，±10%，16V 3 C10 C11 C409
64 0.033UF 0402 X5R，±10%，16V 1 C57
65 0.047UF 0402 X5R，±10%，16V 2 C402 C405
66 0.1UF 0402 X5R，±10%，16V 2 C58 C243
67 0.1UF 0603 X5R，±10%，16V 12
C12 C26 C27 C28 C32
C33 C37 C49
C56 C242 C410 C418
68
1UF
0805
Y5V,
+80,-20%,25V
2 C31 C122
69 NC 0402 2 C244 C346
70 NC 0603 3 C148 R62 R133
Tan Capacitance
71 0.47UF A type ±20% 6.3V 1 C5
72 1UF A type ±20% 6.3V 2 C42 C147
73 2.2UF A type ±20% 6.3V 2 C400 C419
74 4.7UF A type ±20% 6.3V 2 C55 C407
75 6.8UF A type ±20% 10V 1 C245
76 10UF A type ±20% 6.3V 3 C6 C39 C411
Inductor
77
BLM11A601S
BLM18AG601SN1D
0603 Bead 600R 8
L1 L3 L4 L5 L400 L401
L402 L2*
78 LQH32MN1R0M23 1210 Wound，Ferrite 1 L207
Diode
79 LED-02-0603-QGC 0603 Green light 1 LED1
80 LED-02-0603-QRC 0603 Red light 1 LED2
81 1SS372 SOT-323 Detecting tube 1 D400
82 DAN222 SOT-416 DIODE 1 D401
