A-80 UHF SERVICE MANUAL
- 30 -
-023>,cathode
and anode
rubber dot
<L06307-003>)
14
Soft circuit
(T80FPC-2)
S2676B
1
/
TH307H(D03/D47) ASSEMBLED PART BOM
Coding Material Specification Quantity.
F01307-025 TH307H（D03）Semi-manufactured goods 1
Assembled material： plastic parts
P01307-020 Shell 1
P08307-006 Volume knob(small) 1
P07307-006 Channel knob(big) 1
P04307-006 Indicated light guiding pole（light） 1
P02307-003 Anode bracket 1
P12307-002 Belt 1
P16307-003 Belt jack 1
P11307-003 PTT plastic key bracket 1
Single glue:
S07307-003 Speaker dustproof net φ38×48 1
S02307-001 Speaker sponge mat φ16×1（unit：mm） 1
S02307-003 Crystal sponge mat 7×4×1(mm) 2
S06307-005 Radiate silica gel 7×3.8×1.0 1
S08307-001 Waterproof paster 1
Rubber part:
L06307-003 Anode and cathode rubber dot 2
L07307-002 Rubber mic cover 1
L01307-007 PTT rubber key 1
L02307-004 Speaker rubber mat 1
L03307-003 Rubber waterproof loop 1
Metal part:
A02307-002 Antenna seat SMA-JFD-13(New) 1
M17307-006 Aluminum shell 1
M01307-014 Anode reed
Whether need to add
some other material?
1
