A-80 UHF SERVICE MANUAL
- 34 -
○
30
PCB board（A80VHF）
PSW 1.0 J06-A80/01
A80-07-18/1 VHF
1
○
31
MPM025-043 Screw Φ2.5×7PM 2
Plating colorful, cover
and aluminum shell fixing
screw
○
32
T12307-004
Transceiver host mark
(Frequency）
1
“Transceiver type”means
The frequency range mark
T14307-007 Battery mark (Chinese)
1300mA 7.2v 31.6×23.6mm
1
○
33
T14307-008 Battery mark (English)
1300mA 7.2v 31.6×23.6mm
1
Specification bases on
customers requirement
○
34
P10307-004 Battery bottom cover
1 ABS
○
35
P09307-004 Battery surface cover
1 ABS
○
36
M12308-001 Battery touch plate (short)
5.7×5.2mm
4
○
37
P12307-002 Belt 1 ABS
○
38
P16307-003 Belt seat 1 ABS
○
39
M18308-006 Belt spring clip 1
○
40
M18307-008 Belt spring ф0.8 line 1
○
41
M02307-004 Belt spindle Φ1.9×18.8(unit: mm) 1
○
42
M02307-003
Battery clip spindle Φ1.8×20(unit: mm)
1
○
43
M18307-011 Battery lock clip spring
Line diameterΦ0.5mm
1
○
44
P14307-006 Battery lock clip
1
ABS
○
45
P26307-001 Battery buckle plate
1
ABS
○
46
MKM025-022 Screw
Φ2.5×5KM
2
Plating black, fixed on the
battery press plate
○
47
M19040-002 Nut
Φ4.0×3.5×M2.5
2
Brass-color, fixed on the
battery bottom cover
M12308-002
Battery touching
plate(long）
7.7×4.7mm
1
Used on the cathode
○
48
M12307-004
Battery touching
plate(long）
7.7×4.7mm(J type)
1
Used on the anode
○
49
T11308-000 Transceiver host code 2 The transceiver body NO.
