Abell S1 - Page 15

S1 Service manual
15
C60 C85 C150
27 1UF 0402 Y5V, +80,-20%,10V 1 C164
28 1UF 0603 Y5V, +80,-20%,16V 1 C182
29 10UF 0805
X5R，±10%，10V
1 C4
30 NC 0402 NC
C19 C49 C54 C61 C90 C94 C163
C191 R46
R57 R72 R108 R109
Tan-capacitor
31 1UF A type ±20% 16V 2 C99 C142
Inductor
32 BLM18AG601SN1D 0603 0603 bead 600R 2 L6 L32
33 NC 1010 NC L5
Diode
34 LED-02-0603 QGC D0603 Green LED 1 LED3
35 LED-02-0603 QRC D0603 Red LED 1 LED4
36 NC D0603 NC D1
Triode
37 DTC114EE SOT-416 TRANSISTOR 1 Q17
38 DTC114TE SOT-416 TRANSISTOR 1 Q16
IC
39 S-80128ANMC-JCN-T2 SOT-23-5 Restoration IC 1 IC2
40 AT24C08BN-SH SOP8 EEPROM 1 IC1
41
SRT3210
(CS:331DF98B V1.2)
SSOP100
IC320QUAD100 after
writing CPU
1 IC5
Crystal
42 32.768KHz 8.0×3.8mm
CM200C 12.5PF/+
-30PPM
1 Y1
Version：1.0
S1 (D02) B side BOM
Ref.
No
Specification Packing Description Quantity Part No.
Chip Resistor
1 0R 0402 ±5% 7 C59 C140 L20 R27 R42 R102 R120
2 0R 0603 ±5% 1 R140
3 0R 0805 ±5% 1 L45
4 10R 0402 ±5% 7
R12 R13 R33 R35 R124 R126
R128
5 22R 0402 ±5% 2 R34 R127
6 47R 0402 ±5% 1 R137
7 100R 0402 ±5% 4 R16 R71 R86 R87
