S1 Service manual
4
REALIGNMENT
1 MODE
MODE FUNCTION
User Mode Use this mode for normal operation
PC Mode
Use this mode, to make various settings by
means of the FPU through RS-232C port.
Manufacture
Mode
Use this mode, to realign the various
settings through the RS-232C port during
manufacture work.
2 How to enter each mode
MODE PROCEDURE
USER MODE Power on
PC MODE
Connect to the IBM PC compatible
machine and controlled by FPU
3 Setting Acquainted
① PTT (Push-To-Talk) switch
Press this switch, then speak into the microphone to call a station. Release the switch to
receive.
User Mode PC Mode Manufacture Mode
To Next Page
