Abilize Trident - Identification of Parts; Front and Back View Diagrams; Top Control Panel Overview

Instruction Booklet: Identification of Parts
04
Before attempting to drive this scooter on your own, it is important that you familiarise
yourself with the controls and how to operate them.
Figure 1 - Front View
Figure 2 - Top Control Panel Figure 3 - Back View
Charging sockets
Tiller angle
adjustment
Solid tyres
Circuit breaker
Reector
Seat rotation
lever
Release lever
Front basket
Flip-up
armrests
Padded
foldable seat
Easy-to-operate control
panel and delta handlebar
Self-diagnostic warning light
Armrest
adjustment
knob
Anti-tip
wheels
Horn button Battery gauge
Free-
wheeling
lever
Reectors
Speed dial
knob
Main key switch
Throttle
