Basket assembling and disassembling:
• To assemble the basket, slide the front basket (M) over
the hooks on the front of the tiller and into place.
• To disassemble, gently slide the front basket (M) upwards
and off of the hooks on the front of the tiller.
Armrest assembling and angle adjustment:
• Adjust armrest to most comfortable length,
then lock the knob (N).
• Adjust screw (O) height to preferable armrest angle.
Seat height adjustment:
• Remove the seat, then screw, nut and washers from seat post.
• Adjust seat post to desired height, then attach tightly with screw, nut and washers.
• Assemble the seat back to its original position.
• Seat height adjustable 490mm / 515mm / 540mm.
Instruction Booklet: Identification of Parts
07
M
O
N
