TECHNICAL DATA
Operating voltage: STAB 12 VDC -10%/+15%
STAB 24 VDC +/-15%
Current: 0.48 A (12VDC)
0.24 A (24VDC)
Micro switch: max. 0.8 A 30 VAC / VDC resist. Max. 20W
Temperature range: -20
o
C - +60
o
C
Bolt throw: 14mm
Backset: 25, 30 ja 35mm
Forend: 25mm
Functions selected on the lock case:
- opening direction
Indications: - deadlock status
Note!
The lock will not work properly in doors with seal force.
