Installation and Operating Instructions 11
ABS submersible sewage pump AFP 0831S and 0841S
NOTE The ABS service organisation would be pleased to advise you on any applications
you may have and to assist you in solving your pumping problems.
NOTE The ABS warranty conditions are only valid provided that any repair work has been
carried out in ABS approved workshop and where original ABS spare parts have
been used.
6.2 Commentary on maintenance of lifting stations in accordance with EN 12056.
It is recommended that the lifting station be inspected monthly and its function checked.
In accordance with EN regulations, the lifting station should be maintained by a qualified person at the following
intervals:
in commercial premises; every three months.
in apartment blocks; every six months.
in a single family home; once a year.
In addition we recommend that a maintenance contract be taken out with a qualified company.
6.3 Oil filling and oil changing
The oil chamber between the motor and the hydraulic section has been filled at manufacture with lubricating oil.
AFP Oil Chamber Oil Fill Quantity
AFP 50 Hz AFP 60 Hz
Pump Type Litres Pump Type Litres
AFP 0831 S22/4 0.6 AFP 0831 S25/4 0.6
AFP 0841 S13/4 0.6 AFP 0841 S16/4 0.6
AFP 0841 S22/4 0.6 AFP 0841 S25/4 0.6
An oil change is only necessary if a fault occurs.
m
Repair work on explosion-proof submersible pumps may only be carried out by approved personnel in
approved workshops.
When carrying out repairs only original spare parts, supplied by the manufacturer, should be used.
6.4 Cleaning
If the pump is used for transportable applications, then in order to avoid deposits of dirt and encrustation it
should be cleaned after each usage by pumping clear water. In the case of fixed installation, we recommend
that the functioning of the automatic level control system be checked regularly. By switching the selection switch
(switch setting “HAND”) the sump will be emptied. If deposits of dirt are visible on the floats then these should
be cleaned. After cleaning, the pump should be rinsed out with clear water and a number of automatic pumping
cycles carried out.
6.5 Venting of the volute
After lowering the pump into a sump full of water an air lock may occur in the volute and cause pumping
problems. To clear the air lock, raise the pump in the medium and then lower it again. If necessary, repeat this
venting procedure.
•
•
•
