7
SPECIFICATION
Input: 1 × VGA Input (*D-Sub 15pin)
1 × PC-Audio (*3.5mm)
1 × Mic Input (*6.3mm)
1 × USB-B
1 × USB-A
3 × HDMI Input (19 pin female with build in buffer)
Output: 1 × CAT5e/6/7 output (To RX)
1 × HDMI monitor output
1 × Main Stereo Audio
VGA bandwidth: 165MHz (R+G+B), support up to 1600 x 1200
Max resolution: Full HD 1080p (HDMI)
All cable length: Up to 20 meter using CAT-5e or up to 50m using CAT-6A
Control button: Available protocol for each “Control Button” :1
(or × 2 depending on configurations)
LED: LED With LED indication and buzzer for confirmation
Volume: Main Volume Control (Analog)
Mic gain: Microphone Input Gain Control (Analog)
Power adaptor: 12V-DC, 1A
Housing: ABS
Gross dimension: 147 × 88 × 44 mm
Gross weight: 270 g
Typical Applications
Any professional presentation system requiring multiple AV Inputs of all diff erent type of Video standard and a standard
projector controller.
• Schools (Media Classroom)
• Churches
• Corporate Applications (Meeting Room)
