2.2. HDCC72500
1 Locking ring
2 Housing
3 Camera
4 Base plate
5 WDR wiring
Insulated and disconnected: WDR off
Stripped and twisted: WDR on
The analogue output is not available while WDR is activated.
6 Power supply
7 Analogue video output
(BNC, for service purposes, labelled "CVBS")
Only while WDR is off.
8 Analogue HD video output
(BNC, labelled "TVI")
35
