34
English
LOW-LIGHT: Outdoors (with poor reflection properties or no residual light)
APERTURE
Function Description
APERTURE Lens type setting.
Manual (fixed): HDCC62510, HDCC72510: Zoom and focus settings are
performed manually on the lens itself)
HDCC32500, HDCC42500: The lens focus setting has already
been configured at the factory and cannot be changed.
For this model, no setting options are available for this item!
EXPOSURE
Function Description
SHUTTER Exposure time setting
AUTO: Automatic adjustment of the exposure time to the
environmental conditions.
1/25~1/50,000: Fixed exposure time
AGC Setting for max. gain value (upper limit) used by the camera (0~15). The camera
selects the gain value automatically.
SENSITIVITY Continuous exposure setting. Longer exposure times for each image make the
resulting image lighter. However, the longer the exposure time, the lower the
frame rate.
OFF: Continuous exposure deactivated
AUTO (2x~30x): Continuous exposure activated, with value for upper limit
BRIGHTNESS Basic image brightness setting (1~100)
D-WDR Software enhancement of the contrast ratio in the image. Dark areas are
brightened, whilst trying to not increase the brightness of existing light areas.
OFF: Function deactivated
ON: Function activated
DEMIST This function enhances the image quality in the event of a misty camera view.
OFF: Function deactivated
ON: Function activated
POS/SIZE: Reference area size and position setting
DEGR. Intensity levels for the function
RETURN Return to previous menu screen
BACKLIGHT
Function Description
OFF Deactivate all backlight or contrast treatment
WDR Wide dynamic range function. Contrast treatment of the video image through
double exposure (short and long exposure) of the image.
GAIN (LOW/MEDIUM/HIGH): Intensity of the function
