4
Deutsch
3.
Beschreibung der Anschlüsse
Nr.
Beschreibung
1
Spannungsversorgung, 24
V AC
Kabelbelegung:
Schwarz:
24 V AC
Gelb/Grün: Masse
Rot:
24 V AC
2
RS-485 Steuerleitung
Kabelbelegung:
Gelb:
RS-485
Minus
Orange: RS-485
Plus
3
HD-TVI Videoausgang (BNC)
Achten Sie darauf, dass während de
r Installa
tion die Spannungsversorg
ung von der Kamera
getrennt ist.
2
1
3
3
5
