Abus IPCS58571A - Installation on Junction Box; Switching Input;Output

22
3.8 Installation on junction box
An installation box TVAC32500 is available for installation, in order to make cable connections if
necessary (please research alternative model using the product search at www.abus.com).
3.9 Switching input/output
The maximum load values must be observed, otherwise, the camera may be
irreparably damaged.
Description Connection information
Switching input „IN“ Bridge between „IN“ and „G “
„G“ (GND)
Switching output „OUT“ 12 V DC / 24 V AC, max. 500 mA
„G“ (GND)
