Abus TVAC15100 - 4 Description of the Connections; Rear of the Transmitter; Rear of the Receiver

17
English
4. Description of the connections
4.1 Rear of the transmitter
4.2 Rear of the receiver
c
Power supply 5 V DC/1 A (DC, 14.5 x 4.8 mm)
d
AV input Input for the transmitted signal, use the AV cable supplied
e
Pairing button Button for pairing the transmitter and receiver
f
Power switch Switches the transmitter on/off
c
Power supply 5 V DC/1 A (DC, 14.5 x 4.8 mm)
d
AV output
Output for representing the transmitted signal, use the
AV cable supplied
e
Pairing button Button for pairing the transmitter and receiver
f
Power switch Switches the receiver on/off
AV IN
PAIRING
PAIRINGAV OUT
DC IN 5 V /1 A
DC IN 5 V /1 A
c
d e
f
c
d e
f
