20
Description of the function keys
Select the desired input signal. The current input is displayed overlaid in
the upper left corner of the screen.
The following options are available:
S-video, VGA and CVBS (BNC)
Pressing this button will take you to the menu.
You can navigate between the menu items by pressing this button
repeatedly.
You can set the following values:
Bright= brightness
Contrast= contrast
Color= colour
Hue= hue
It is possible to set values between 0 and 99 on all menu items. This can
be changed using the buttons “+” and “RES-”.
Press this button in the menu to increase the values for the various menu
items. Holding down the button makes the values increase faster.
Press this button in the menu to reduce the values for the various menu
items. Holding down the button makes the values decrease faster.
Press this button in live cast to select the various 4:3 resolutions:
800*600 pixels @ 60 Hz
800*600 pixels @ 75 Hz
1.024*768 pixels @ 60 Hz
1.280*1.024 pixels @ 60 Hz
1.600*1.200 pixels @ 60 Hz
Press this button in live cast to select the various wide screen resolutions:
1.280*720 pixels @ 60 Hz
1.366*768 pixels @ 60 Hz
1.440*900 pixels @ 60 Hz
1.600*900 pixels @ 60 Hz
1.680*1.050 pixels @ 60 Hz
1.920*1.080 pixels @ 60 Hz
1.920*1.200 pixels @ 60 Hz
