Abus TVAC20001 - Guide to the Connections and Buttons

19
English
4. Guide to the connections and buttons
Front
Rear
Description of the connections
VGA IN
VGA signal input for a recorder or PC, for example
5-12 V DC
Power supply. 5-12 V DC/1 A
S-VIDEO IN
Y/C video signal input
CVBS IN
Composite video signal input (BNC, female, CVBS, 1 Vss)
VGA OUT
VGA output of the converted signal
5-12 V DC
S-VIDEO IN
CVBS IN
VGA OUT
POWER LED
INPUT
MENU
+
RES/-
WIDE SCREEN
VGA IN
Function keys
