Abus TVCC12020 - Technical Data

English
20
9. Technical data
Model number
TVCC12020
Image sensor
1/4" Sony CCD
DSP
Sony Effio-E
Camera type
Pinhole super-mini-camera
Resolution
520 TVL
Pixels (total)
537(H) x 597(V)
Pixels (effective)
512(H) x 582(V)
Lens
3.7 mm, pinhole lens
Horizontal angle of view
51°
Lens control
AES
Minimum illumination (color)
0.05 lux @ F2.0
Electronic shutter
1/50 sec – 1/100,000 sec
White Balance
ATW, 2,400 – 11,000 K
Amplifier control
Auto
Backlight compensation
BLC
Dynamic range (WDR)
-
Video system
PAL
Synchronization
Internal
Connections
1 x BNC (FBAS, 1 Vp-p, 75 ohm),
1 x DC (5.5 x 2.1 mm)
Power supply
12 V DC
Power consumption
75 mA
Operating temperature
0 °C ~ +50 °C
Humidity
0 ~ 85% (non-condensing)
Protection class
IP34
Dimensions (H x D)
29.4 x 22 mm
Weight
17.5 g
Certifications
CE, RoHS, REACH
