AC MGA0800/A1 User Manual

11
Main interface
T01 Cabinet internal temp-
erature
T02 Evaporator temperature
T03 Condenser temperature
T04 Cabinet internal humidity
E01 Cabinet internal high
temperature alarm
E02 Cabinet internal low
temperature alarm
E03 Cabinet internal tempErature
sensor alarm
E04 Evaporator tempErature
sensor alarm
E05 Condenser tempErature
sensor Alarm
E06 Evaporator- frozen alarm
E07 System high pressure alarm
P01 Refrigeration starting temperature setting
Size: 25～45
P02 Refrigeration return difference setting
Size: 3～10
P03 High temperature alarm setting
Size: 25～45
P04 Low temperature alarm setting
Size: 30～60
P05 Heating starting temperature setting
Size:-30～15
P06 Heating return difference setting
Size:5～15
P07 Communication address setting
Size: 0～255
Code input interface
(User：001）
Definition
Icon
DefinitionIcon Icon
Definition
5.3 Display
Under running, the main interface 8.8.8 displays real temperature value in cabinet
After boot, in any interface, if there has no keyboard operation in the continuous 60s,
automatically return to the main interface
5.4 Start self-test
In the running states, the self-checking function can be activated by continuous pressing
SET
for 3
seconds.
When Self-check, the screen will be full display for 1S, and then will normally display cabinet
temperature, while the boot icon will blink.
6 Running
6.1 Check before start running
1) There are not obvious blockages near the internal cycle air inlet and outlet of the
air conditioner.
2) The input power cables and other signal cables have been connected reliably
and correctly.
