AC STAG-4 QBOX PLUS User Manual

AC S.A. all rights reserved. Under penalty of law and/or liability claims it is forbidden to copy, publish, distribute, make available and/or use in any way all or any part of information contained
within this document, in particular photographs, drawings, illustrations, trademarks, etc
11
Tab. 1 Table of versions
VOLVO S40 / V50 / C30 / C70
Engi
ne
Year of
manufac
ture
Petrol ECM harness
Installation notes
Conne
ctor
Pin
No.
Wire colour
Signal
2.5T
2005
B
20
white-black
Fuel pump control signal
ECM location
A
91
white-blue
Fuel pressure sensor signal
2006
÷
2011
B
21
white-black
Fuel pump control signal
A
89
white-blue
Fuel pressure sensor signal
VOLVO S60
Engi
ne
Year of
manufac
ture
Petrol ECM harness
Installation notes
Conne
ctor
Pin
No.
Wire colour
Signal
2.5T
2004
÷
2009
B
47
yellow
Fuel pump control signal
ECM location
A
2
green-grey
Fuel pressure sensor signal
3.0T
2010
÷
2011
B
21
yellow-orange
Fuel pump control signal
ECM location
A
71
blue-red
Fuel pressure sensor signal
VOLVO S60 R
Engi
ne
Year of
manufac
ture
Petrol ECM harness
Installation notes
Conne
ctor
Pin
No.
Wire colour
Signal
2.5T
2004
÷
2009
B
47
yellow
Fuel pump control signal
ECM location
A
2
green-grey
Fuel pressure sensor signal
VOLVO S80
Engi
ne
Year of
manufac
ture
Petrol ECM harness
Installation notes
Conne
ctor
Pin
No.
Wire colour
Signal
2.5T
2004
÷
2006
B
47
yellow
Fuel pump control signal
ECM location
A
2
green-grey
Fuel pressure sensor signal
2007
÷
2011
B
21
yellow-orange
Fuel pump control signal
A
89
blue-brown
Fuel pressure sensor signal
